Ground Zero GZIW 12XSPL-D2

EAN: 4037072023664
GZIW 12XSPL-D2
Ground Zero Iridium 12″ XSPL-subwoofer.
Read more
Description
Specifications

Description

12″ High-power XSPL subwoofer Klippel optimized New reinforced paper cone with 3D honeycomp structure.

- 2.5″ copper voice coil
- High-roll sandwich surround progressive 2-layer spider
- Push terminals

Don´t get fooled by the affordable price! These budget class XSPL-monsters are designed with Klippel-optimization to squeeze out every single desibel that is possible to get. Voice coil cooling is very efficient and long excursion gives you a LOT of bass. Very linear impedance curve makes it possible to really extract all the power from the amp to these subwoofers.

Specifications

- 12″ XSPL Subwoofer
- Progressive 2-layer spider
- Voice coil 63 mm / 2.5″
- Impedance 2 x 2 Ohm
- Re 4.33 Ohm
- Fs 32,5 Hz
- Qms 10.76
- Qes 0.79
- Qts 0.73
- Vas 40.4 L
- Le 2.48 mH
- Mms 231 gr
- Bl 15.9
- Xmax 34 mm / 1.34″
- Effiency ( SPL 1w / 1m )
- Power handling ( SPL ) 1000 Watts
- Rec. amplifier power 500 - 1000 Watts
- Outer diameter 310 mm / 12.2″
- Mounting cut out 285 mm / 11.22″
- Mounting depth 162 mm / 6.38″

Recommended enclosures:
- Vented 45L net
- Port 10cm / 4″, length 21cm

- Bandpass ( 4th order ) 25L net sealed / 40L net vented
- Port 10cm / 4″, length 11cm
- Tuning frequency Fb 57 Hz
-Bandwith 35 - 100 Hz.
