Ground Zero GZNW 30XMAX-II

EAN: 4037072026801
GZNW 30XMAX-II
12″
Xmax-subwoofer
3000W
2 x 1 Ohm
3″ voice coil
Effective x-max: 80 mm
Read more
1 pcs
Description
Specifications

Description

Are You ready for Xmax?!

New replacement for legendary GZNW 12 is finally here. Developing the new Xmax-series was extraordinary challenging, because predecessors have set standards so high.

New High Roll surround is developed from world famous GZ SPL-surround and it keeps its form even in peak to peak use. There are many manufacturers that have similar looking surrounds, but usually those loose their control long before reaching their maximum suspension travel. With new GZ Xmax-woofers you do not have to worry about this.

Very high excursion demands many changes to inner motor structure to control the airflow and provide sufficient cooling to voice coil. Usually it is impossible to play frequencies over 40 Hz with subwoofers that have 80-120 mm excursion because higher frequencies cause turbulence to motor making voice coil to overheat due to insufficient cooling. We are proud to say that Xmax-subwoofers are the only very high excursion subwoofers that keep their sound quality excellent from 10 to 70 Hz band and keep the voice coil cool without turbulence.

Xmax-subwoofers are the first very high excursion subwoofers that are Klippel-optimized. All components are perfectly balanced.

If you like to do hairtricks and flex-videos, look no further. Choose Xmax.

Specifications

Type High-Performance Low-Bass-Subwoofer
Diameter 30 cm / 12″
Power handling (RMS) 3000 Watts
Impedance 2x 1 Ohm
Efficiency 83 dB
Power recommendation 2000 – 4000 Watts
Voice coil 75 mm / 3″ CCA
Cone Aluminum
Max. excursion (Xmax) 60 mm / 2.36″
Mounting Ø 282 mm / 11.10″
Mounting depth 250 mm / 9.84″
Resonance frequency (Fs) 35.6 Hz
Damping ratio (Qts) 0.61
Equiv. air volume (Vas) 13.6 L / 0.48 cu.ft.
