Pioneer DMH-AF555BT
EAN: 4988028500718
DMH-AF555BT
Pioneer 2-din multimedia receiver with 9″ floating screen
Read more
Description
Specifications
Media
Description
Experience Power in Simplicity with Pioneer DMH-AF555BT. Equipped with Pioneer’s signature specifications, Pioneer Sound Tuning Features, an immersive infotainment system and seamless smartphone connectivity powered by WebLink®, we give you the freedom to experience enhanced in-car entertainment on your terms with the touch of a fingertip. Just touch, customize, and repeat.
9″ Large Screen Display
Easy-To-Use High-Quality Capacitive Touch Screen
Pioneer Bass Boost
Pioneer Sound Tuning Features
Built-in 4x50W Amplifiers
Immersive Infotainment System Powered By WebLink®
Seamless Smartphone Mirroring With WebLink® Cast
Navigate With WebLink
Weather Update With WebLink
Back-Up Camera Ready (Camera sold separately)
9″ Large Screen Display
Easy-To-Use High-Quality Capacitive Touch Screen
Pioneer Bass Boost
Pioneer Sound Tuning Features
Built-in 4x50W Amplifiers
Immersive Infotainment System Powered By WebLink®
Seamless Smartphone Mirroring With WebLink® Cast
Navigate With WebLink
Weather Update With WebLink
Back-Up Camera Ready (Camera sold separately)
Specifications
Display
9.0” WSVGA Full Flat Display – Floating Design
DIN Size
2-DIN
WebLink ® Infotainment System
Yes
Pioneer Bass Boost
Yes
Pioneer Crossover Setting
Yes
Pioneer Equalizer
Yes
Back-Up Camera Ready
Rear camera input
Bluetooth
Yes (AVRCP 1.6)
USB Interface
1 x USB Interface supporting Full HD playback and 1.5A Quick Charge
AUX Input
Rear
Audio Format
WMA / MP3 / WAV / AAC / FLAC
Video Format
H.264 / MPEG4 / WMV
Audio Output (RCA)
1 system x front, 1 system x rear, 1 system x subwoofer
(13-Band Graphic Equaliser):
Frequency: 50 Hz/80 Hz/125 Hz/200 Hz/315 Hz/ 500 Hz/800 Hz/1.25 kHz/2 kHz/3.15 kHz/5 kHz/8 kHz/12.5 kHz Gain: ±12 dB (2 dB/step)
HPF: Frequency: 25 Hz/32 Hz/40 Hz/50 Hz/63 Hz/80 Hz/ 100 Hz/125 Hz/160 Hz/200 Hz/250 Hz
Subwoofer/LPF: Frequency: 25 Hz/32 Hz/40 Hz/50 Hz/63 Hz/80 Hz/ 100 Hz/125 Hz/160 Hz/200 Hz/250 Hz
Bass boost: Gain: +12 dB to 0 dB (2 dB/step)
Mounting Dimension
(W) 178mm x (H) 100mm x (D) 110mm
9.0” WSVGA Full Flat Display – Floating Design
DIN Size
2-DIN
WebLink ® Infotainment System
Yes
Pioneer Bass Boost
Yes
Pioneer Crossover Setting
Yes
Pioneer Equalizer
Yes
Back-Up Camera Ready
Rear camera input
Bluetooth
Yes (AVRCP 1.6)
USB Interface
1 x USB Interface supporting Full HD playback and 1.5A Quick Charge
AUX Input
Rear
Audio Format
WMA / MP3 / WAV / AAC / FLAC
Video Format
H.264 / MPEG4 / WMV
Audio Output (RCA)
1 system x front, 1 system x rear, 1 system x subwoofer
(13-Band Graphic Equaliser):
Frequency: 50 Hz/80 Hz/125 Hz/200 Hz/315 Hz/ 500 Hz/800 Hz/1.25 kHz/2 kHz/3.15 kHz/5 kHz/8 kHz/12.5 kHz Gain: ±12 dB (2 dB/step)
HPF: Frequency: 25 Hz/32 Hz/40 Hz/50 Hz/63 Hz/80 Hz/ 100 Hz/125 Hz/160 Hz/200 Hz/250 Hz
Subwoofer/LPF: Frequency: 25 Hz/32 Hz/40 Hz/50 Hz/63 Hz/80 Hz/ 100 Hz/125 Hz/160 Hz/200 Hz/250 Hz
Bass boost: Gain: +12 dB to 0 dB (2 dB/step)
Mounting Dimension
(W) 178mm x (H) 100mm x (D) 110mm
