SounDigital SD800.4 EVOX2 4 ohm
Description
The 800.4 EVOX2 is a compact, modern amplifier that delivers 800W RMS of power over 4 channels.
EVOX2 is the best series that SounDigital has ever made!
The amplifier features exclusive and patented technologies that make the sound experience cleaner and more faithful, in addition to ensuring better performance and efficiency for the most daring projects.
Features:
- New better circuit board
- New RCA connectors
- Better cooling than before
- Renewed signal input: improved interference distance
- better audio quality
Specifications
Power @ 2Ω: 4 X 200W
Power @ 4Ω: 4 X 132W
Bridge Power @ 4Ω: 2 X 400W
Bridge Power @ 8Ω: 2 X 264W
Frequency Response (-3dB):
5Hz ~22kHz
Low Pass Filter (12dB/octave):
45Hz ~ 850Hz
High Pass Filter (12dB/octave):
45Hz ~ 850Hz
Operating Voltage:
8V ~ 16V
SNR:
91dB
Input Sensitivity (RCA):
0.2V ~ 2V
Input Sensitivity (High Level input):
1.5 ~ 15V
Current Draw (Music):
35A
Current Draw With Resistive Load:
88A
Total Efficiency:
80%
Damping Factor (@100Hz nominal impedance):
200
Power Cable:
10mm² (7 AWG)
Audio Output Cable:
2 x 1.5mm (15AWG)
Recommended Fuse (Music):
40A
Recommended Battery (Minimum):
60Ah
Width:
4.4 in / 11,3 cm
Length:
5.8 in / 14,8 cm
Height:
2 in / 5,1 cm
