AI-Sonic BTA3.200
Bluetooth 5.0
2x 50W + 100W ( sub )
230Vac/ 12-24Vdc
Audio input ( RCA )
SUB out ( RCA )
Description
The BTA3.200 is a powerful 2.1 channel Bluetooth amplifier designed for high-quality audio performance.
The unit’s two amplifier channels are designed for passive speakers, while the third, more powerful channel is designed for a subwoofer. The subwoofer can be either active or passive, as the BTA3.200 has connections for both options. The subwoofer crossover frequency can also be adjusted
( subwoofer crossover frequency adjustment range: 26–160 Hz ).
The BTA3.200 features adjustable treble, bass, subwoofer frequency, subwoofer volume and master volume controls - allowing precise sound customization.
With Bluetooth & RCA audio connectivity it works seamlessly with most home passive speakers and passive / active subwoofers.
Powered by a low-distortion BTA2.300 chips, it delivers clear, detailed and high-definition sound.
( normally the power adapter is sold separately, but by purchasing this kit, you get the power supply included free of charge )
Specifications
Max power output: 2 x 50W + 100W ( subwofer )
Subwoofer frequency tuning: 26 - 160Hz
Load impedance: 4 - 8 Ohm
Frequency range: 20Hz - 20kHZ
Input interface: BT / RCA Audio in
Output interface: Passive speakers, active subwoofer
THD: 1%
Power amplifier chip: BTA3.200 x 2pcs
Power adapter 24V/5A - 12V/10A ( normally the power adapter is sold separately, but by purchasing this kit, you get the power supply included free of charge )
Bluetooth transmission distance: 10 m
Dimension 13 x 13 x 3.5 cm
Product weight: 500 g
